Backplanes PICMG 1.0

BP3/16

bp3_16

The BP3/16 features PICMG® 1.0 backplane supports sixteen 32-bit/33MHz PCI and two ISA option card slots along with a PICMG 1.0 compliant Single Board Computer slot.

BP7/6

bp7_6

The BP7/6 has PICMG® 1.0 backplane supports six 32-bit/33MHz PCI and six ISA option card slots along with a PICMG 1.0 compliant SBC slot.

BP3/16-64

BP3/16-64 PICMG 1.0 Backplane

The The BP3/16-64 is a PICMG® 1.0 backplane supports sixteen 64-bit/33MHz PCI and two ISA option card slots along with a PICMG 1.0 compliant Single Board Computer (SBC) slot.

BP3/10

BP3/10 Backplane

The BP3/10 is a PICMG® 1.0 backplane supports ten 32-bit/33MHz PCI and two ISA option card slots along with a PICMG 1.0 compliant Single Board Computer (SBC) slot.



Legacy 1.3 SHB

NLI

NLI PICMG 1.3 System Host Board

The NLI PICMG 1.3 System Host Board single processor configuration optimized for maximum performance and value. The NLI features an Intel® Xeon® processor and the Intel® E7520 chipset. SHB features include an 800MHz system bus, dual channel DDR2-400 memory interfaces, dual Gigabit Ethernet ports, dual Serial ATA/150 ports, dual USB 2.0 ports with two additional USB 2.0 interfaces and an advanced Ultra XGA video port. PCI Express, PCI and PCI-X option card support makes the NLI an ideal choice for a variety of applications.

NLT

NLT PICMG 1.3 System Host Board

The NLT PICMG 1.3 System Host Board features high-speed SHB-to-backplane PCI Express® links. Two single-core Intel® Xeon® processors with the Intel® E7520 chipset supports an 800MHz system bus, dual channel DDR2-400 memory interfaces, dual Gigabit Ethernet ports, dual Serial ATA/150 ports, dual USB 2.0 ports with two additional USB 2.0 interfaces and an advanced Ultra XGA video port. PCI Express, PCI and PCI-X option card support makes the NLT an ideal choice for current as well as future industrial computing applications.

MCGI

MCGI SIngle Board Computer

The MCG series of PICMG® 1.3 System Host Boards offers a wide variety of board configurations designed to excel in the most demanding graphics-class computing applications. Dual-Core processor options provide two and Quad-Core processors provide four execution cores per processor. For dual-processor board configurations, each processor has its own independent system bus to reduce data bottlenecks while maximizing processing throughput. The four-channel memory interface features DDR2-667 FB-DIMMS with a maximum of 16GB. An extended-memory SHB configuration is available that supports up to 32GB of system memory. The processing power and configuration flexibility built into the MCG-series give system designers and their customers the best technology fit for their graphics-class PICMG 1.3 computing applications.

MCGT

MCXI Single Board Computer

The MCG series of PICMG® 1.3 System Host Boards offers a wide variety of board configurations designed to excel in the most demanding graphics-class computing applications. Dual-Core processor options provide two and Quad-Core processors provide four execution cores per processor. For dual-processor board configurations, each processor has its own independent system bus to reduce data bottlenecks while maximizing processing throughput. The four-channel memory interface features DDR2-667 FB-DIMMS with a maximum of 16GB. An extended-memory SHB configuration is available that supports up to 32GB of system memory. The processing power and configuration flexibility built into the MCG-series give system designers and their customers the best technology fit for their graphics-class PICMG 1.3 computing applications.



PICMG 1.0 SHB

T4I

T4I Single Board Computer

The T4I Single Board Computer (SBC) supports the Intel® 845E chipset and the Intel® Pentium® 4 processor. A flexible board design enables you to scale the T4I to closely match processing power with application need.

T4G

T4G Single Board Computer

The T4G is a cost-effective PICMG 1.0 SBC for low-end embedded computing applications. This SBC supports the Intel® 845GV chipset and the Intel® Pentium® 4 processor. Advanced video and graphics capabilities along with the Intel® Pentium® 4 processor enables the T4G to maximize system value and performance. Of course, all this comes with the quality and long-life embedded product support you expect.

MX8

MX8 Single Board Computer

The MX8 Single Board Computer is a PICMG 1.0 single board computer (SBC) that offers flexible processor options, including the Intel® Pentium® 4 processor with its 800MHz system bus and 1M L2 cache, and the Intel® Celeron® processor with a 400MHz system bus and 128K of L2 cache memory. The capabilities of the MX8 include dual Gigabit Ethernet, dual Serial ATA/150 and dual channel DDR266/333/400 memory support. The chipset’s AGP 4x video connection to a 16MB ATI® video controller gives the MX8 the power for demanding video applications. The MX8 supports new PCI-X and PCI option cards, as well as legacy ISA option cards. Enabling PCI-X, PCI and ISA option card communications makes the MX8 the ideal SBC for implementing new systems and for upgrading older systems.

T4R

T4R Single Board Computer

The T4R Single Board Computeris specifically designed to simplify upgrading older Intel® Pentium®, Intel Pentium® II or Intel® Pentium® III SBCs with a high performance Intel® Pentium® 4 or a Mobile Intel® Pentium® 4 Processor-M single board computer. The T4R generates its own +3.3V on board and provides the ability to route the +5V over to the +12V lines of the T4R’s processor. These power control features enable the T4R for use as a simple drop-in SBC upgrade in PICMG® 1.0 embedded computing systems.
